Esperanza Sur (ES01)

ILS RWY 25

LOC 109.95 · IKMG

LOC

109.95 IKMG

FINAL CRS

247°M

GS / TCH

3.0° / 52′

DA (CAT I)

690′ (200′)

TDZE

490′

APT ELEV

489′

Missed approach: climb on track 247°M to 3,500′, then direct MA25 (IKMG DME 5.5 on the localizer course) and hold, right turns, 1-minute legs, inbound 247°M, maintain 3,500′.

Notes: DME or GPS required. Missed-approach hold at MA25 is identified by IKMG DME on the localizer course.

Plan view · north up · not for navigation

Profile view · not to scale

Straight-in minimums

CAT I DA(H)	690′ (200′)
RVR / VIS	550 m / 1,800 ft

Runway & lighting

RWY 25	3,937′ · asphalt
Lighting	MALSR · PAPI 3.0° · edge
