Auto-published plate

NDB Test Field (ZNDBT)

NDB RWY 02

NDB 340 kHz · TNB

NDB

340 kHz TNB

FINAL CRS

024°M

GP / TCH

3.0° / 52′

MDA

4,420′ (513′)

TDZE

3,907′

APT ELEV

3,907′

Missed approach: climb on track 024°M to 7,000′, then RIGHT turn direct TNB NDB and hold, right turns, 1-minute legs, inbound 024°M, maintain 7,000′.

Notes: ADF required. The beacon carries no DME - identify NF02 to MAP by timing (table below) or GPS distance. Course reversal at NI02; the missed approach returns to the TNB beacon - the whole procedure flies on the ADF alone.

Plan view · north up · not for navigation

Profile view · not to scale

NF02 to MAP · 5.0 NM

Gnd speed kt	70	90	100	120	140
Time	4:17	3:20	3:00	2:30	2:09

Straight-in minimums

NDB MDA(H)	4,420′ (513′)
VIS	1,600 m / 1 SM

Runway & lighting

RWY 02	3,937′ · asphalt
Lighting	as installed
