La Maison de Paille (LFMDP)

Lavaré, France

NDB RWY 05

NDB 345 kHz · LAV

NDB

345 kHz LAV

FINAL CRS

046°M

GP / TCH

3.0° / 52′

MDA

920′ (520′)

TDZE

400′

APT ELEV

400′

Missed approach: climb on track 046°M to 3,500′, then RIGHT turn direct LAV NDB and hold, right turns, 1-minute legs, inbound 046°M, maintain 3,500′.

Notes: ADF required. The beacon carries no DME - identify NF05 to MAP by timing (table below) or GPS distance. Course reversal at NI05; the missed approach returns to the LAV beacon - the whole procedure flies on the ADF alone.

Plan view · north up · not for navigation

Profile view · not to scale

NF05 to MAP · 5.0 NM

Gnd speed kt	70	90	100	120	140
Time	4:17	3:20	3:00	2:30	2:09

Straight-in minimums

NDB MDA(H)	920′ (520′)
VIS	1,600 m / 1 SM

Runway & lighting

RWY 05	1,969′ · gravel
Lighting	as installed
