Fort Ashby Valley (KFAV)

RNAV (GPS) RWY 10

RNP APCH · LNAV/VNAV

APCH

RNP LNAV/VNAV

FINAL CRS

100°M

GP / TCH

3.5° / 60′

DA (VNAV)

1,360′ (246′)

TDZE

1,114′

APT ELEV

1,114′

Missed approach: climb on track 100°M to 4,200′, then direct RM10 and hold, right turns, 1-minute legs, inbound 100°M, maintain 4,200′.
Notes: GPS required.

Plan view · north up · not for navigation

RI1010.0 NMRF105.0 NM100°MRM104,200′N5 NM

Profile view · not to scale

RW103,032′GP 3.5°RI1010.0 NMRF105.0 NMTCH 60′4,200′

Straight-in minimums

LNAV/VNAV DA(H)1,360′ (246′)
LNAV MDA(H)1,510′ (400′)
VIS1,600 m / 1 SM

Runway & lighting

RWY 106,562′ · concrete
LightingPAPI

Auto-published from the airport design · for Microsoft Flight Simulator only — not for real-world navigation.
